8GE Port Gigabit Unmanaged Industrial PoE Ethernet Switch

Model: EKI-2708G-PI

Category:

Booth No: N/A

Characteristic

The EKI-2708G PoE switch is an unmanaged Ethernet switch supporting 8 ports of PoE+ (Power over Ethernet) and compliant with IEEE 802.3at/af standards. It provides up to 30 watts of power per port and fulfills a power budget of a maximum of 240 watts on systems with power input ranging from 12 to 48VDC. The switch also provides a relay output for event alarms, which activates the alarm to notify administrators. With a robust design for harsh environments, DIN rail mounting, and fast startup with plug-and-play functionality. The EKI-2708G supports IEEE 802.3/802.3u/802.3z/802.3ab/802.3x with 10/100/1000 Mbps, full/half-duplex, auto-negotiation, and MDI/MDI-X auto-sensing, providing an economical solution for your industrial Ethernet network.

Features:
 8 x Gigabit Ethernet ports or plus 2 Gigabit SFP ports
 Support 8 x IEEE 802.3at/af PoE ports for PD demands
 Up to 30W output per PoE port
 Supports jumbo frame transmission up to 9k bytes
 DIN-rail with IP30 metal mechanism
 12 ~ 48 VDC redundant dual power input and 1 relay output
 Wide operating temperature range of -40 ~ 75°C
