SEIKO-Optical Encoder IC
Model: SMD-04B
Category: Key Components
Exhibitor: SHENG TUNG DEVELOPMENT CO., LTD.
Booth No: N/A
Characteristic
・Package：HCOB14 5.3×4.3×1.0mm
・Power supply ：4.5～5.25V
・Power consumption：22mA
・Operation temperature ：-30～+85℃
・2 phase(Sin wave, A/B) analog output(20um/cycle)
Noise-resistant differential output
・APC Function :LED brightness auto power
control function to reduce
variation in analog output
signal amplitude
